The PTxx series pressure transmitters have been designed for a wide range of industrial applications. They are capable of measuring pressure in water, gases, or vapors in systems such as liquid level monitoring, pump control, and machine building.

The gauge sensors use silicon-based sensing diaphragms with high elasticity, combined with semiconductor strain gauges implanted into the silicon substrate. This configuration provides excellent sensitivity, high overpressure resistance, and precise measurement characteristics with low non-linearity, minimal hysteresis, and high repeatability.

The relative pressure models rated for 25 bar and 60 bar employ ceramic capacitive measuring cells, ensuring robust performance in demanding environments.

Thanks to their technical specifications, reliability, and cost-effectiveness, these pressure transmitters are especially well suited for OEM applications.
